Our Large Span Steel Structure Logistics Warehouse is a high-performance storage solution engineered for modern supply chains, combining exceptional load-bearing capacity, spatial flexibility, and rapid construction. Crafted with premium Q345B/Q235B steel, this warehouse features a span range of 24-60m (customizable) without intermediate columns, maximizing usable storage space for containers, pallets, and heavy equipment. Compliant with ISO 9001, CE, and AISC standards, it ensures durability (50+ year service life) and resilience against 8-grade earthquakes, 12-level winds, and extreme temperatures (-30℃ to 60℃). Ideal for global logistics, manufacturing, and distribution centers, the Large Span Steel Structure Logistics Warehouse balances cost-efficiency and operational productivity.
|
Parameter |
Specification |
|
Span Range |
24m - 60m (customizable) |
|
Eave Height |
6m - 15m |
|
Steel Grade |
Q235B, Q345B (optional Q460) |
|
Load Capacity |
0.5-1.2kN/㎡(roof); 5-20kN/㎡(floor) |
|
Service Life |
≥50 years |
|
Fire Rating |
Class B (optional Class A with fireproof coating) |
|
Wind Resistance |
≤0.75kN/㎡ (12-level wind) |
|
Earthquake Resistance |
≤8 degrees |
|
Construction Period |
30-90 days (based on 1000-5000㎡) |
Core Features: ① Large span design eliminates internal columns, increasing storage utilization by 30% vs. traditional warehouses; ② Lightweight steel structure reduces foundation costs by 25-35%; ③ Prefabricated components enable fast on-site assembly; ④ Corrosion-resistant (galvanized/Zinc-aluminum coating) and low maintenance.
Applications: Global logistics hubs, container yards, cold storage facilities, manufacturing distribution centers, and bulk cargo warehouses—suitable for cross-border logistics, e-commerce fulfillment, and industrial supply chain management.
The Large Span Steel Structure Logistics Warehouse undergoes strict precision manufacturing: ① BIM 3D modeling for structural optimization; ② Automated CNC cutting (tolerance ±1mm) and welding (AWS D1.1 standard); ③ Hot-dip galvanizing (Z275) for corrosion protection; ④ 3-stage quality inspection (material → processing → finished product) with SGS certification. All components are labeled, packaged in waterproof containers, and delivered with detailed assembly drawings for seamless global transportation and installation.
